| Measurements | | Metric | US |
| Working height max.(1) | | 20.87 m | 67 ft 11 in |
| Platform height max. | | 18.87 m | 67 ft 11 in |
| Horizontal reach max. | | 12.42 m | 40 ft 9 in |
| Below ground reach | | 2.46 m | 8 ft 1 in |
| Up and over clearance max. | | 7.8 m | 25 ft 7 in |
| A Platform length (8 ft/6 ft) | | 0.91 m / 0.76 m | 3 ft/2 ft 6 in |
| B Platform width (8 ft/6 ft) | | 2.44 m / 1.83 m
| 8 ft/6 ft |
| C Height - stowed (tires) | | 2.54 m | 8 ft 4 in |
| C Height - stowed (TraX) | | 2.59 m | 8 ft 6 in |
| C storage/transport (jib tucked under - Tires/TraX) | | 2.90 m / 2.95 m | 9 ft 6 in / 9 ft 8 in |
| D Length - stowed (tires) | | 9.45 m | 31 ft |
| D Length - stowed (TraX) | | 9.75 m | 32 ft |
| D Length - storage/transport (jib tucked under) (Tires/TraX) | | 7.44 m / 7.75 m | 24 ft 5 in / 25 ft 5 in |
| E Width | | 2.49 m | 8 ft 2 in |
| G Width (TraX) | | 2.58 m | 8 ft 6 in |
| F Wheelbase | | 2.49 m | 8 ft 2 in |
| G Ground clearance - center (tires) | | 0.41 m | 1 ft 3 in |
| G Ground clearance - center (TraX) | | 0.43 m | 1 ft 5 in |
| Productivity | | | |
| Lift capacity max. - unrestricted | | 227 kg | 500 lb |
| Platform rotation | | 180° | 180° |
| Jib length | | 1.52 m | 5 ft |
| Vertical jib rotation | | 135° | 135° |
| Turntable rotation | | 360° | 360° |
| Turntable tailswing | | 0 cm | 0 cm |
| Drive speed - stowed(2) | | 4.8 km/h | 3.0 mph |
| Drive speed - stowed (TraX) | | 3.7 km/h | 2.3 mph |
| Drive speed - raised (tires) | | 1.1 km/h | 0.68 mph |
| Drive speed - raised (TraX) | | 1.1 km/h | 0.68 mph |
| Gradeability - stowed(2) | | 30 % | 30 % |
| Tilt sensor activation (front to back/side to side) | | 4.5° / 4.5° | 4.5° / 4.5° |
| Turning radius - inside/outside (tires, 4WD) | | 2.80 m / 5.71 m | 9 ft 2 in / 18 ft 9 in |
| Turning radius - inside/outside (TraX) | | 3.48 m / 6.50 m | 11 ft 5 in / 21 ft 4 in |
| Tires (solid, non-marking) | | 355 / 55 D625 | 355 / 55 D625 |
| Power | | | |
| Power | | Diesel | Diesel |
| Auxiliary power unit | | 12 V DC | 12 V DC |
| Hydraulic tank capacity | | 132 L | 35 gal |
| Fuel tank capacity | | 132 L | 35 gal |
| Weight(3) and Floor Loading(4) | | | |
| Weight, 2WS | | 10,063 kg | 22,185 lb |
Weight (TraX)
| | 10,292 kg | 22,690 lb |
| Tire contact pressure | | 75.8 kPa | 11 psi |
| Occupied floor pressure (tires) | | 11.83 kPa | 247 psf |
| Sound and Vibration Levels | | | |
| Sound Pressure level (ground workstation) | | 84 dBA | 84 dBA |
| Sound Pressure level (platform workstation) | | 79 dBA | 79 dBA |
| Vibrations | | 2.5 m/s2 | 8 ft 2 in/s² |
